Direct Drive Linear Motor Has Integrated Encoder and Temperature Sensor for Increased Throughput!

Motion Control – Linear Actuator Gives Higher Throughput!

motion control Voice coil motor with temperature sensor



MotiCont-Logo

Van Nuys, CA – Motion Control Products – The new patented SDLM-019-070-01-01 direct drive linear motor with integrated position and temperature sensors is the latest addition to the series of zero backlash, zero cogging, high acceleration, high speed, high resolution, long life motors from Moticont. Also known as an electric cylinder, this compact direct drive linear motor is just 0.75 in. (19.1 mm) in diameter and 2.75 in (69.9 mm) long.  Protected inside the motor housing, the linear optical quadrature encoder is directly connected to the shaft for the greatest possible accuracy. Highest throughputs are achieved by the SDLM-019-070-01-01 linear motor when operating at peak efficiency monitoring the data from the internal temperature sensor.

The SDLM-019-070-01-01 direct drive linear motor has a stroke length of 0.500 in. (12.7 mm) and a continuous force rating of 7.3 oz. (2.0 N) and peak force of 23.0 oz (6.4 N).  This non-commutated direct drive servo motor features: Quiet long life, plain linear bearings, an integrated internal 1.25 micron resolution (0.000049 in.) quadrature optical encoder with differential outputs, and a non-rotating shaft.  Applications include: Manufacturing (assembly and inspection equipment), sorting and packaging, semiconductor handling, medical procedure tables and instruments, antenna positioning, dampers, door & valve actuators, agricultural equipment, shaking, and adjustable office furniture.

Direct coupling of the load or stage to the low inertia non-rotating shaft eliminates backlash and allows for high acceleration/deceleration.  Both ends of the actuator and shaft ends have threaded mounting holes for easy integration into new and existing applications. The SDLM-019-070-01-01 Direct Drive Linear Actuator is also available with a matching servo controller

About Moticont – About Moticont – Moticont is a manufacturer of motion control products. Their product line includes voice coil motors, three phase brushless motors and positioning stages and slides.

Moticont is committed to exceeding their customers’ quality expectations and industry standards throughout the design, manufacturing, service and technical support phases. Their modern manufacturing facility, highly controlled processes, committed staff, and extensive testing complement their product design strengths. This enables them to supply their clients with specialized small orders to high volume just-in-time deliveries.

They offer an extensive line of standard products ready to be shipped immediately from stock, and when standard products are not quite right for an application, highly trained design engineers are always available to develop custom motion control products to fit the specific needs or our customers.

For additional information contact Sales Team at Moticont, 6901 Woodley Ave, Van Nuys, CA 91406; Toll Free: +1 (888) 785-1804, Tel: +1 (818) 785-1800, moticont@moticont.comor visit the website at http://www.moticont.com


See this and other Motion Control Components from Moticont featured on:

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

MotiCont-Logo
Visit our Website
Other Products
Videos

Motion Control – Motorized Yaw-Pitch-Roll Stages Available from OES!

Motion Control – Yaw-Pitch-Roll Stages

motion control - yaw, pitch, and roll stages



OES Logo

Van Nuys, CA – — Motion Control – Three new high accuracy Yaw-Pitch-Roll stages have been introduced by OES (Optimal Engineering Systems, Inc.), the YPR100-10-15-01 (stepper motor driven – pictured), the YPR100-10-15-02 (brushless servo motor driven) and the YPR100-10-15-03 (DC servo motor driven). These Yaw-Pitch-Roll stages are ideal for the precise measurement of compound angles or the curvature of an object. The Yaw axis (bottom stage) is capable of rotation of large angles and features a 180:1 ratio gear. The positional accuracy is 0.05 degrees and repeatability is +/- 0.01 degrees. The Pitch axis (middle stage) has cross roller guides and a range of travel of +/- 10 degrees and has an accuracy of 0.05 degrees and repeatability of +/-  0.01 degrees.

The Roll axis (top stage) has cross roller guides and a range of travel of +/- 15 degrees and the 65 mm x 65 mm table has a precise pattern of threaded holes for fixtures or tooling. This stage has an accuracy of 0.05 degrees and repeatability of +/-  0.01 degrees and the total center deflection for all axes is 0.03 mm. The rotation center height is 50 mm.

The Pitch and Roll axes are equipped with end of travel limit switches. The yaw axis has a HOME signal for initialization. Additionally all axes have a calibrated indicator to display the angle of rotation. The maximum speed with stepper motors is 14 degrees/second and 90 degrees/second with servo motors.

The knobs of stepper motors can be replaced with optional optical encoders for position verification.  The YPR100-10-15-02 and YP110-10-03 feature servo motors and optical quadrature encoders for very precise closed loop operation and greater speeds.  The YPR100-10-15 stages can be ordered plug-and-play with a fully a compatible multi-axis motion controller from OES.

About OES – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders.

Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.

For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com


See this and other Motion Control Components from OES (Optimal Engineering Systems, Inc.) featured on:

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://MotionControlMarketing.com

http://Gotcha-Stick.com

OES Logo
Visit OES Website
OES Facebook
OES Twitter
OES Videos

Motion Control – Check out the new integrated powerful brushless motor and a positioning controller available from Maxon!

Motion Control – Integrated Brushless Motor Controller!



motion control - Maxon

motion control integrated motor / controllerEven Stronger, Even Smaller

Fall River, MA — Motion Control – See the new modular compact drive that was developed especially for applications in industrial and logistics automation. The IDX drive combines a powerful, brushless EC-i motor and an EPOS4 positioning controller, which can be complemented with a maxon planetary gearhead when required. This drive stands out for its high efficiency, maintenance-free components, and a high-quality industrial housing with IP65 protection. It also features configurable digital and analog inputs and outputs, and intuitive software enabling easy commissioning and integration into master systems.

A solution for confined spaces

Speaking of positioning controllers: The maxon EPOS4 is now also available in a Micro version. As the name suggests, the benefits of these motion controllers are their small size and attractive pricing. The EPOS4 Micro 24/5 is suitable for robotic applications where space is at a premium, and cost-sensitive multi-axis applications.

Contact maxon for more details info@maxonmotorusa.com

Comprehensive documentation and software are included with every delivery, and are also available for you to download from our website at www.maxonmotor.com.

Maxon Banner


See this and other Motion Control Components from Maxon featured on:

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

Maxon Logo
Visit our Website
Order Our Catalog

Motion Control – Linear Servo Controller for Non-Commutated Motor from Equipment Soultions!

Motion Control – Linear Servo Controller

motion control - Servo Control Amplifier



Equipment Soultions

Forestville, CA, – Motion Control – The SCA814 Linear Servo Controller was specifically designed to control single phase, non-comutated devices like voice coil motors. like it’s field proven predecessor the SCA754 is a high performance single axis DC motor controller and amplifier system. It is comprised of a highly integrated single PC board level product with a cohesive interface. This card provides current amplification and analog servo control interfaces. The single-phase characteristic of the current amplifier makes it particularly well suited for DC motors such as galvanometers and voice coils. It was specifically developed for control of motor applications requiring both high temporal and spatial servo precision, such as machine vision, inspection, scientific imaging, medical imaging and other business applications. This amplifier interfaces directly to many of the Equipment Solution motor/stage solutions.



Besides galvanometers the SCA814 is directly compatible with all the ESI linear voice coil stages and the optical scanners. A bipolar linear or switching regulated power supply is required by the SCA814 amplifier. Typically better performance can be achieved when using a linear power supply. Equipment Solutions has several high-current supplies for this purpose including the SPS15 ±15V DC Switching Power Supply.

motion control - Amplifier specifications

motion control - interface drawings

motion control - servo diagram
Equipment Solutions, Inc. (ESI) is a provider of engineering and manufacturing services. ESI specializes in the design and production of automation and instrumentation products including motion control components and sub systems. ESI’s products range from galvanometer amplifiers with an integrated arbitrary waveform generator, to high-resolution displacement sensors, voice coil and stepper motor stages, amplifiers and controllers.

For additional information contact Jeff Knirck at Equipment Solutions,Inc. Mailing Address – PO Box 159, Forestville, CA 95436; Shipping Address 6490 Front Street, Forestville, CA 95436; Tel: 408-245-7162, Fax: 408-245-7160, E-Mail: info@equipsolutions.com or visit the Website at http://www.equipsolutions.com


See this and other Motion Control Components from Equipment Solutions featured on:

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://MotionControlBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://Gotcha-Stick.com

http://MotionControlMarketing.com

Equipment Soultions
Visit our Website
Motion Control - Follow Equipment Solutions on Twitter
Motion Control - Follow Equipment Solutions on Facebool
View Equipment Solutions Motion Control Blog

Motion Control – Linear Motion Systems and the Ideal Choice for Running Two Systems in Parallel

Motion Control – Linear Slides and Components

motion control - linear slide



Motion Control - Electromate-Logo



Vaughan, Ontario, Canada — Motion Control Components — Bishop-Wisecarver invented the DualVee® guide wheel over 50 years ago in four sizes of carbon steel as a component-based problem solver for harsh, debris-laden environments. It’s 2019. They now offer product options that include UtiliTrak® linear guides, LoPro® linear actuators to complete actuated system solutions.

LoPro® Linear Actuators excel in high speed, long length and dirty environments. UtiliTrak® is constructed with DualVee Motion Technology® in vee and vee/crown designs, and using MadeWell® Crown Rollers, and are perfect for commercial applications in need of a compact, easy-to-install, and low maintenance solution.



motion control components UtiliTrak

Both LoPro® and UtiliTrak® are available as part of the Bishop-Wisecarver QuickShip Program (ships from the facility within 3 business days).

Learn how LoPro® and UtiliTrak® can be the ideal linear guide solutions for your packaging application.

CLICK HERE to view Information on the LoPro® Linear Actuators from Bishop-Wisecarver

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Blog: https://electromate.wordpress.com/

Electromate Best Blace to Work

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com


See this and other Motion Control Components from Electromate featured on:

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://MotionControlBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://Gotcha-Stick.com

Motion Control - Electromate-Logo
Visit our Website
Motion Control - Electromate Twitter Link
Motion Control - Electromate Facebook Link

Motion Control Tutorial – Slotted vs. Slotless Motor Technology

motion control Servo2Go-Logo

Motion Control – Tutorial Motor Technology

Motion Control Tutorial – When first introduced, brushless DC motors, despite their many advantages, were cast as a costly alternative to brush-commutated motors and were typically only specified for low-power applications where long life was the primary desired requirement. Without the mechanical brush-commutator mechanism that would wear and eventually result in motor failure, brushless motors could be relied upon to deliver performance over time. As for other advantages, conventional wisdom held that brushless motors provide high speed and fast acceleration, generate less audible noise and electromagnetic interference, and require low maintenance. Brush-commutated motors, on the other hand, would afford smooth operation and greater economy. In the past decade, though, brushless motors have gained broader appeal and greater acceptance in industry for a wider range of applications previously dominated by brush-commutated products, due in part to dramatic reductions in the cost and size of electronic components and advances in motor design and manufacturing.

motion control Tutorial

At the same time, manufacturers have further sought to challenge conventional wisdom by improving brushless motor design in an effort to combine the traditional advantages of brush-commutated and brushless types. A noteworthy example of how far these innovations have progressed involves the slotless (instead of slotted) construction of the brushless motor’s stationary member, or stator.

The slotless stator design originated with the goal to deliver smooth running performance and eliminate cogging, which is an unwanted characteristic especially in slower-running applications (less than 500 rpm). The absence of cogging is, in fact, the most-often cited reason for selecting a slotless brushless motor.

Slotted Motor Construction

Most brushless motors (slotted or slotless) use electronic commutation, usually Hall-effect sensors and magnets, in place of brushes. The motor’s rotor consists of a steel shaft with permanent magnets or a magnetic ring fixed around the circumference of the shaft. The magnets are responsible for producing torque. As the flux density of the magnet material increases, the amount of torque available from the rotor assembly increases.

In traditional slotted brushless motors, the stator features a group of slotted steel laminations (0.004 in. to 0.025 in. thick), which are fused to form a solid uniform stack and create a series of teeth. Wound copper coils, which produce electromagnetic fields, are then inserted into each of the slots. Together, the laminated stack and wound copper coil form the stator assembly. The return path completing the magnetic circuit consists of the laminated material outboard of the copper windings in the stator and the motor housing.

These brushless slotted motors are especially powerful, because the teeth around which the copper wire is wound place the iron closer to the magnets, so the magnetic circuit is completed more efficiently. As the air gap between iron and magnets is reduced, the torque available for the motor is increased.

However, slotted stators are known to cause cogging, which is attributed to the teeth in their construction. Cogging occurs when the permanent magnets on the rotor seek a preferred alignment with the slots of the stator. Winding copper wires through the slots tends to increase this effect. As magnets pass by the teeth, they have a greater attraction to the iron at the ends of the teeth than to the air gaps between them. This uneven magnetic pull causes the cogging, which ultimately contributes to torque ripple, efficiency loss, motor vibration, and noise, as well as preventing smooth motor operation at slow speeds. A slotless stator offered a solution to the problems experienced with cogging in slotted brushless DC motors.

Advantage of the BLDC Slotted Motor Technology

The main advantages of the slotted technology are:

  • ease of winding customization
  • increased heat dissipation
  • ability to withstand high peak torque
  • high power density

Slotted Motor Applications

The Slotted Motor is ideal for applications such as:

  • Medical Hand Tools
  • Hand held shaver system for arthroscopic surgeries
  • High speed surgical drills for ENT surgeries

Slotless Motor Construction

Instead of winding copper wires through slots in a laminated steel stack as in conventional slotted brushless motors, slotless motor wires are wound into a cylindrical shape and are encapsulated in a hightemperature epoxy resin to maintain their orientation with respect to the stator laminations and housing assembly. This configuration, which replaces the stator teeth, eliminates cogging altogether and results in desired quiet operation and smooth performance.

The slotless design also reduces damping losses related to eddy currents. These currents are weaker in a slotless motor, because the distance between the laminated iron and magnets is greater than in a slotted motor.

Slotless motors are typically designed with sinusoidal torque output that produces negligible distortion, rather then a trapezoidal voltage output. The sinusoidal output reduces torque ripple, especially when used with a sinusoidal driver. Because the slotless design has no stator teeth to interact with the permanent magnets, the motor does not generate detent torque. In addition, low magnetic saturation allows the motor to operate at several times its rated power for short intervals without perceptible torque roll-off at higher power levels.

Compared with slotted motors, slotless construction also can significantly reduce inductance to improve current bandwidth. The teeth in a slotted motor naturally cause more inductance: the coils of copper wire around the teeth interact with the iron in a slotted motor, and this interaction tends to send the current back on itself, resulting in more damping (or dragging) and impacting negatively on slotted motor response and acceleration.

In terms of delivering power, conventional slotted motors used to enjoy the advantage over slotless types, due (as noted) to the proximity of iron and magnets and the reduced air gap.

However, this advantage has virtually evaporated, in large part due to the utilization of high-energy, rare-earch magnets (such as samarium cobalt and neodymium iron boron). By incorporating these magnets, manufacturers of slotless brushless motors have been able to routinely compensate for the greater air-gap distance. These more powerful magnets effectively enable the same (or better) torque performance for slotless products compared with slotted. Eliminating the teeth and using stronger magnets both serve to maximize the strength of the electromagnetic field for optimum power output. Rare-earth magnets, along with the fact that fewer coils, or “turns,” of the wire are required in slotless motors, also help contribute to low electrical resistance, low winding inductance, low static friction, and high thermal efficiency in slotless motor types.

One more important difference between slotless and slotted designs is the rotor diameter. Slotless motors have a larger rotor diameter than slotted construction for the same outside motor diameter and will generate a higher inertia, as well as accommodating more magnet material for greater torque. For applications with high-inertia loads, the slotless product is more likely to be specified.

Slotless Motor Applications

In general, brushless motors are usually selected over brushcommutated motors for their extended motor life. (While motor life is application-specific, 10,000 hours are usually specified.) Other reasons for specifying brushless motors include a wide speed range, higher continuous torque capability, faster acceleration, and low maintenance.

In particular, slotless versions of brushless DC motors will suit those applications that require precise positioning and smooth operation. Typical niches for these motors include computer peripherals, mass storage systems, test and measurement equipment, and medical and clean-room equipment.

As examples, designers of medical equipment can utilize slotless motors for precise control in machines that meter and pump fluids into delicate areas, such as eyes. In medical imaging equipment, slotless brushless DC motors decrease banding by providing the smoother operation at low speeds. Airplane controls supply smoother feedback to pilots. And, by eliminating cogging and resulting vibration, these motors can reduce ergonomic problems associated with hand-held production tools. Other appropriate applications include scanners, robots for library data storage, laser beam reflector rotation and radar antenna rotation equipment, among many others./span)

Customization Options

Slotless brushless DC motors, as with most motors today, feature a modular design so they can be customized to meet specific performance requirements. As examples, planetary or spur gearheads can be integrated on motors for an application’s specific torque and cost requirements. Planetary gearheads offer a higher-torque alternative. Slotless motors can further be customized with optical encoders, which provide accurate position, velocity, and direction feedback that greatly enhances motor control and allows the motors to be utilized in a wider range of applications. As a low-cost alternative to optical encoders, rotor position indicators (ie. Hall Sensors) can be specified.

When using optical encoders, differential line drivers can be utilized to eliminate the effects of electrically noisy environments. Differential line drivers are designed to ensure uncorrupted position feedback from the encoder to the control circuit.

Motor Selection Guided by Application

Despite the overall design and performance comparisons reviewed here for slotless and slotted brushless DC motor types, one should remain cautious in drawing any conclusion that one type is the ultimate choice over the other. There are simply too many variables that must be evaluated, ranging from rotor size and windings to housing and special components. A given application and its requirements should (and will) be the guiding factors in selecting a particular motor type and the customized components to be incorporated.

Some encouraging news in those applications that would clearly benefit from a slotless brushless motor is that costs are coming down to be more in line with those for slotted motors. This is because of new streamlined manufacturing techniques and an increasingly available supply of powerful magnets, which are both beginning to have a positive impact on end-product costs.

Regardless of any cost differential, however, for many applications, slotless brushless DC motors will be the preferred choice to resolve specific requirement issues. While advances in electronics are beginning to be applied that promise to reduce normal cogging in slotted products as a step toward making these motors more smooth running and quiet, the industry is not there yet: slotless motors remain the best alternative where cogging and life are defining performance issues

This Tutorial and other Motion Control Tutorials are available through www.Servo2Go.com

For further information on this new product or others in our extensive product portfolio, call 1- 877-378-0240 or e-mail Warren Osak at warren@servo2go.comor visit Servo2Go.com at: www.Servo2Go.com

See this and other Motion Control Components from Servo2Go featured on:

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://MotionControlMarketing.com

http://Gotcha-Stick.com

Servo2Go-Logo
Visit our Website
Twitter Link
Facebook Link

Motion Control – Two Axis X-Theta Voice Coil Positioning System from H2W Technologies

Motion Control – Two Axis X-Theta Positioning System

motion control - multi axis system

H2W Logo

Santa Clarita, CA —– Motion Control – H2W Technologies introduces a high acceleration, voice coil driven, XY-Theta positioning stage with a precision bearing system, which minimizes the amount of pitch, yaw, and roll in the system.  The voice coil stage (VCS02-005-BS-01-MXYTh) is a closed loop positioning system that can be used for positioning applications that require a limited rotation theta stage integrated. The stage utilizes a custom low-profile design that utilizes a unique electromagnetic circuit design. The motor has a two-axis planar coil assembly that interacts with a common magnetic circuit.  This circuit design allows for a minimal overall height of 2.93 inches [74.5 mm].

Each linear axis has a 0.23″ [6.0 mm] stroke; generate 0.50 lbs [2.2 N] of continuous force and 1.50 lbs [6.6 N] of peak force.  The X and Y axes are guided by precision linear ball slide assemblies. It includes a one-micron resolution magnetic linear encoder on each linear axis.  The theta axis has a rotary displacement of 10 degrees, a continuous torque of 2.2 in-lbs [0.25 Nm], and a peak torque of 6.5 in-lbs [0.73 Nm]. There is also encoder feedback on the theta axis that has 239000 counts per revolution. This design utilizes a moving coil in all three axes, which has a lower moving mass that enables the highest possible acceleration. Voice coil positioning stages are ideal for applications that require quick, short moves with fast settling times.

Features:

  • – Three-axis motion control
  • – High acceleration
  • – Compact footprint
  • – Custom strokes and force configurations available
  • – Cable carrier to route customer payload cables

About H2W Technologies, Inc.

H2W Technologies, Inc. is dedicated to the design and manufacture of linear and rotary motion products that are used in the motion control industry. The complete line of linear electric motors includes: Single and dual axis linear steppers, DC brush and brushless linear motors, voice coil actuators, and AC induction motors. Also offered is a complete line of ball screw, lead screw and belt driven positioning stages.

Other motion control products include: Limited angle torque motors for compact, limited angular excursion rotary servo applications, 3 phase brushless rotary servo motors with matching digital servo amplifiers and permanent magnet linear brakes for fail-safe, zero power braking for baggage handling and people moving applications as well as amusement park rides.

With over 75 years combined experience in the linear and rotary motion field, the H2W Technologies team of engineers offers the optimal solution to the most demanding motion control, requirements.

For additional information contact Mark Wilson at H2W Technologies, 26380 Ferry Ct, Santa Clarita, CA 91350; Tel: 888-702-0540, Fax: 661-251-2067, E-Mail: info@h2wtech.com or visit the website at http://www.h2wtech.com


See this and other Motion Control Components from H2W Technologies featured on:

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com





H2W Logo
Visit our Website
You Tube
Visit our Blog

Motion Control – Case Study – Ball Screws used in Wearable Pumps!

Motion Control – Case Study: Wearable Pumps!

motion control ball screw application



Steinmeyer Logo



The Next Generation of Intelligent Balloon Catheters Depend on Novel Designs of Ball Screw Driven Pumps

Woburn, MA –Motion Control Components Ball Screws – Case Study –

Situation:

In the realm of cardiovascular assist devices, recent developments have focused on fully implantable pumps. Among the first was HeartMate, quickly followed by Impella and HeartWare. Fully implantable devices are very expensive to develop and produce. Plus they are limited to patients who can tolerate the highly invasive procedure.

A key development in cardiovascular assist devices would be to combine the less-invasive approach of implantable balloons and external pumps with the high portability and reliability of fully implantable systems. This advance would allow the treatment of a much wider range of patients and conditions. A Steinmeyer customer set out to develop an innovative pump to achieve this advance in an intra-aortic system



Challenge:

One of the main technical challenges to this approach is designing a wearable pump that can carefully control the balloon’s pressurization. The pump must meet a demanding combination of performance requirements, including:

  • Precise control of pressure
  • Reversible pressurization
  • Light weight
  • Compact size
  • Quiet operation
  • Continuous performance for at least one year

Meeting these requirements was a significant challenge for their engineers. They built and tested early prototypes using traditional designs such as diaphragm pumps. But this approach required separate chambers for positive and negative pressure. The resulting systems were far too large and heavy. So they were forced to find a new approach.

motion control ball screw medical application

Results:

Their main innovation was selecting a precision ground ball screw as the drive mechanism and pairing it with a custom engineered metal bellows as the pressure chamber. Ball screws deliver exceptional thrust density while enabling high linear acceleration in both the forward and reverse directions. Surrounded by the bellows, this results in an extremely compact and quiet design. Ball screws are also known for their high efficiency (>90%), smooth operation, and long life. Their efficiency enables the use of small motors and low power consumption, which in turn reduce the size and weight of the entire system.

The engineers turned to Steinmeyer to ensure the smoothest running, highest quality ball screw. And they also knew that Steinmeyer was extremely well-qualified to provide technical support through all stages of development. Their system is meeting all of its design requirements and will soon enter late stage clinical trials.

motion control application medical

To Download a PDF of this Case Study Go To – https://ballscrew-tech.com/2017/05/26/wearable-pumps-for-medical-devices-count-on-ball-screws/



motion control case study wearable pumps

Future:

There is an emerging trend in the development of balloon catheters to serve cardiovascular applications. Intelligent balloon catheters may one day be key to innovation. These devices will use flexible sensors and electronics along the catheter for data collection and therapeutics. They will also incorporate balloons to apply mechanical force in the heart and arteries. Ball screw driven pumps will support these future systems as well.

About Steinmeyer

Steinmeyer is the world’s longest continuously-operating manufacturer of commercial ball screws. In the realm of linear motion control, our company has become synonymous with precision, innovation, and exacting standards of quality.

Steinmeyer’s extensive product line is used widely in drive systems for industrial machines as well as precision positioning in optical instruments, medical devices, and other mechatronic applications.

Contact Steinmeyer for further information on their extensive product portfolio:

781-273-6220

infoUSA@steinmeyer.com

Visit Steinmeyer.com

Steinmeyer Ball Screw Resource Center



Other Interesting Case Studies from Steinmeyer:

For the Case Study “Custom Linear Modules for Lithography Masking” CLICK HERE

For the Case Study “Pipetting” CLICK HERE


See this and other Motion Control Ball Screws, Stages, Technology Notes, Custom Components from Steinmeyer featured on:

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

Steinmeyer Logo
Visit our Website
Steinmeyer Motion Control Videos
Other Steinmeyer Motion Control Ball Screw Blog

New Harmonic Drive FHA-C Mini 24V Servo Actuator with Dual Absolute Encoder and Panel Mount connectors!

Motion Control – Harmonic Drive  Servo Actuator

motion control harmonic drive servo actuator



Motion Control - Electromate-Logo



Vaughan, Ontario, Canada — Motion Control Components — Introducing Dual Absolute encoder versions of the FHA-C mini actuator. Featuring BiSS-C Harmonic Drive fha-24v-002bi-directional communication for both encoders. The dual encoders are incorporated in essentially the same package size as the long-standing FHA-C mini single incremental encoder version. Without increasing the size, the dual absolute encoder offers single turn absolute position at the output, without the need for battery back-up. Panel mount connectors come standard, and customers can choose between 4 exit options.

The FHA-C mini Series is a family of extremely compact actuators that deliver high torque with exceptional accuracy and repeatability. The actuator combines a high precision Harmonic Drive® gear component with a pancake brushless servo motor. A single turn 14 bit (16384 cpr) gear output encoder has been integrated along with a single turn 14 bit (16384 cpr) motor input encoder providing a true absolute encoder that does not require a battery within 360° of rotation of the output. Typical multi-turn encoders monitoring the motor input shaft require a battery to store the current position when power is lost to the system; however, the dual absolute encoder overcomes this need. In other words, No Battery Required. When power is restored the actuator knows its position.

Features include:

  • Zero backlash
  • Incremental, Absolute or Dual Absolute Encoder
  • 24VDC winding
  • High-torque/weight and torque/volume ratio
  • Optional flex-rated cables with sealed connectors

Information on the FHA-C mini actuator from Harmonic Drive can be viewed at: https://www.electromate.com/assets/catalog-library/pdfs/harmonic-drive/harmonic-drive-fha-mini-24vdc-specsheet.pdf

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Blog: https://electromate.wordpress.com/

Electromate Best Blace to Work

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com


See this and other Motion Control Components from Electromate featured on:

http://LinearmotionBlogger.com

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://MotionControlBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://Gotcha-Stick.com

http://MotionControlMarketing.com



Motion Control - Electromate-Logo
Visit our Website
Motion Control - Electromate Twitter Link
Motion Control - Electromate Facebook Link

Motion Control – Compact, High Resolution Resonant Scanner Features Wide Frequency Range and Fully Integrated Control & Drive Electronics!

Motion Control – Resonant Scanner

motion control resonant scanner



Equipment Soultions

Forestville, CA — The RS-25 Resonant Scanner from Equipment Solutions is optimized for applications that typically require a means to scan an optical beam. This motion control resonant scanner is a very efficient means of oscillating or vibrating a mirror or similar load at a fixed frequency. Up to a 25 mm diameter mirror can be set at the factory to oscillate at a fixed frequency of 20 Hz to 550 Hz, and mirror sweep can be adjusted to a total of 90 degrees optical. The very compact RS-25 Resonant Scanner measurers just 25 x 58 x 21 mm and all electronics necessary to control and drive the scanner are fully integrated. Typical applications include: 3D laser digitizing & measurement, printing, raster scanners, laser projectors, laser marking, laser range finding, barcode scanning, confocal microscopy, FLIR, retinal image acquisition, semiconductor inspection, laser tuning, and biological and medical research.

The RS-25 Resonant Scanner can optionally be configured with a very high-resolution position sensor. This non-contact electro-optic sensor provides a means to directly monitor the angular position of the user’s load with micro-radian scale resolution and repeatability. The sensor naturally produces an analog signal proportional to position and is noise limited, however, options include a high-resolution 16-bit Analog-to-Digital converter to quickly sample and report the mirror position (up to 1500 samples-per-second) at any time.

Unparalleled performance and reliability have been achieved through a continuous and careful attention to every design detail. This relentless drive has generated patent pending concepts and ideas that distinguish the RS-25 Resonant Scanner. The RS-25 Resonant Scanner has a virtually unlimited life. Carefully designed flexures mimic a conventional spring-mass harmonic motion system, and a small voice coil motor coupled to the system compensates for small system loses that would otherwise dampen the oscillation.

Two connectors are accessible from the side of the unit. One, a mini USB connector, supports high speed USB communications and power sourcing. The second connector provides electrical control and signal interfaces (e.g. analog amplitude control and feedback (e.g.) mirror position).

Additional features include: Very low power drive electronics (low heat emission), vertical or horizontal mounting, high frequency stability (to 0.05%), broad frequency selection, no wearing parts, shock and vibration tolerant.

Equipment Solutions, Inc. (ESI) is a provider of engineering and manufacturing services. ESI specializes in the design and production of automation and instrumentation products including motion control components and sub systems. ESI’s products range from galvanometer amplifiers with an integrated arbitrary waveform generator, to high-resolution displacement sensors, voice coil and stepper motor stages, amplifiers and controllers.

For additional information contact Jeff Knirck at Equipment Solutions,Inc. Mailing Address – PO Box 159, Forestville, CA 95436; Shipping Address 6490 Front Street, Forestville, CA 95436; Tel: 408-245-7162, Fax: 408-245-7160, E-Mail: info@equipsolutions.com or visit the Website at http://www.equipsolutions.com


See this and other Motion Control Components from Equipment Solutions featured on:

http://EquipmentSolutions-Blog

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

Equipment Soultions
Visit our Website
Motion Control - Follow Equipment Solutions on Twitter
Motion Control - Follow Equipment Solutions on Facebool
View Equipment Solutions Motion Control Blog
